em-trak B921 "CSTDMA" AIS Transponder Class B 2Watt transmit power 430-0001
Item no. EMT-10015
The em-trak B921 Class B AIS transponder has a standard 2W transmit power (CSTDMA) and is an improved successor to the B100, which is the most widely used AIS transponder in the world.The B921 is small and light, yet delivers the best-in-class AIS receive and transmit performance, so you can see more AIS information and targets at maximum range - all achieved with the lowest...
Technical details
Your selected configuration: Standard
Contact me with the item number if you need more technical information about this product.
Full product description
The em-trak B921 Class B AIS transponder has a standard 2W transmit power (CSTDMA) and is an improved successor to the B100, which is the most widely used AIS transponder in the world.
The B921 is small and light, yet delivers the best-in-class AIS receive and transmit performance, so you can see more AIS information and targets at maximum range - all achieved with the lowest power consumption.
With built-in intelligent connectivity, an integrated 2nd generation GPS receiver and antenna, and a unique FLEXI-FIT™ mounting bracket system, installation is safe and simple.
Overview:
Certified AIS Class B - 2W CSTDMA
Global certification - USCG / FCC / Canada / Europe
SRT-AIS™ Transceiver Engine proven to offer unmatched performance
FLEXI-FIT™ mounting system for easy, practical and safe installation
Internal high-performance GPS receiver and antenna (external antenna optional)
Water, pressure and moisture resistant (IPx7 & IPx6 certified)
Protected against vibrations, shock, and extreme temperatures
Small and lightweight
Ultra-low power consumption - best in class
NMEA0183 & NMEA2000
Automated health and performance monitoring
Silent Mode (transmit-off) function
Improved RF screening to protect against electromagnetic interference
Built-in surge protection
PHYSICAL SPECIFICATION:
Size 150 X 110 mm
Weight 320g
ELECTRICAL SPECIFICATION:
Power Supply 12 - 24v Dc
Power Consumption 1.65W (135mA @ 12V)
Galvanic Isolation NMEA0183 Inputs Only
CONNECTORS:
VHF Antenna Output SO239
VHF Radio Input N/A
GNSS Antenna TNC
Standard 5 Way NMEA2000 Micro Connector
Power/NMEA0183 12 Way Circular Multipole
USB Micro B
DATA INTERFACES:
Physical Data Interfaces NMEA0183 (2) NMEA2000 & USB
WiFi Type N/A
Bluetooth Type N/A
STANDARDS COMPLIANCE:
AIS Standards IEC62287-1 ED 3, ITU-R M.1371-5,
Product Safety Standards EN60950-1 2006 +A11:2009
+A1:2010 +A12:2011 +A2:2013 EN62311:2008
CFR 47 PT1.1310 (2016)
Health Canada Safety Code 6
ARPANSA Radiation Protection Series No.3
Environmental Standard IEC60945 EDITION 4
Serial Data Interface Standards IEC61162-1 ED 5.0
IEC61162-2 ED 1.0
GNSS Performance Standards IEC61108-1 ED 2.0
IEC61108-02 ED 1.0
NMEA2000 Interface Standard NMEA2000 EDITION 3.101
VHF TRANSCEIVER:
Access Scheme CSTDMA
Operating Frequency Range 156MHz To 163MHz
AIS Receiver Sensitivity -111dBm
AIS Transmit Power 2W (+33dBm)
GNNS RECEIVER & ANTENNA:
Channels 72
GNNS Type & Performance GPS/Galileo + GLONASS or BEIDOU
Environmental Standard:
Category Exposed
Water Proofing Ipx6 And Ipx7
Operating Temperature -25ºc To +55ºc
IN THE BOX:
1 X AIS TRANSCEIVER
1 X POWER AND DATA CABLE (2M)
1 X VHF RADIO ACCESSORY CABLE
1 X FLEXI-FIT MOUNTING BRACKET
COMPLETE WITH SCREWS OR OPTIONAL FIXING TAPE
