Fusion® XS Series marine speakers, 120-watt 4" classic marine speakers (pair)

Item no. FUS-10252

Fusion® XS Series marine speakers, 120-watt 4" classic marine speakers (pair)

Giv musikken plads om bord, når kursen er sat og der er tid til at nyde turen.

  • Til lydgengivelse som del af et kompatibelt lydsystem.
  • Fysiske mål (diameter): 4" (klassisk): 135 mm (5,31")(Klassisk/sport) på 6,5": 81 mm (6,97") (Klassisk/sport) på 7,7": 196 mm (7,72")
  • LED belastningsstrøm ved 14,4 V DC (maks.): 150 mA (kun udvalgte sportsmodeller)
  • Kontinuerlig effekthåndtering (RMS): 4": 30 W6,5": 50 W 7,7": 60 W
Your selected configuration

Standard

Price each
859,00 DKK

Includes VAT. Shipping calculated at checkout.

Delivery time confirmed after ordering
View delivery terms

Split your payment with ViaBill or Anyday

See amounts and terms with the provider. Choose your payment method at checkout.

See what is included and what the installation requires

What is included

  • 12 Phillips monteringsskruer i rustfrit stål (3,5 mm x 25,4 mm/6 måler x 1")
  • 12 Phillips monteringsskruer i rustfrit stål (4,2 mm x 25,4 mm/8 måler x 1")
Technical details

Your selected configuration: Standard

Fysiske mål (diameter)4" (klassisk): 135 mm (5,31")(Klassisk/sport) på 6,5": 81 mm (6,97") (Klassisk/sport) på 7,7": 196 mm (7,72")
Fysiske mål (dybde)4" (klassisk): 68 mm (2,68")(Klassisk) på 6,5": 81 mm (3,19") (Sport) på 7,7": 83 mm (3,27")(Klassisk) på 7,7": 94 mm (3,7") (Sport) på 7,7": 97 mm (3,82")
Monteringsdiameter, frirum4": 99 mm (3.9")6,5": 135 mm (5.31") 7,7": 162 mm (6.38")
Monteringsdybde, frirum4": 54 mm (2.13")6,5": 67 mm (2.64") 7,7": 77 mm (3.03")
LED belastningsstrøm ved 14,4 V DC (maks.)150 mA (kun udvalgte sportsmodeller)
Kontinuerlig effekthåndtering (RMS)4": 30 W6,5": 50 W 7,7": 60 W
LED-forsyningsspænding10,8-16 VDC (kun udvalgte sportsmodeller)
Produkt/modelFusion® XS Series marinehøjttalere, 120 watt klassisk marinehøjttaler (par) på 4"
ProducentFusion
Frekvensrespons (+/- 3 dB)4": 100 Hz-18 kHz6,5": 80 Hz-18 kHz 7,7": 70 Hz-18 khz
Størrelser4"/6,5"/7,7"
FarveKlassisk hvid/sort eller sport grå/hvid
Vand- og støvklassifikationIP65
HøjttalertypeKoaksial
Følsomhed (SPL ved 1 W/1 m)4": 87 dB6,5": 91 dB 7,7": 92 dB
Nominel impedans4 Ω
LED-belysningJa – RGB (kun udvalgte sportsmodeller)
Driftstemperatur0° til 50° C (32° til 122° F)
Kegle materiale4": Polypropylenkegle med gummikant6,5"/7,7": polypropylenkegle med stof-surround
DiskanttypeAluminiumskuppel
Sikkerhedsafstand for kompas4": 255 cm (100.5")6,5": 310 cm (122") 7,7": 400 cm (157.5")
HøjttalerforbindelserSpadestik
LED-forbindelseEndeforbindelser (kun udvalgte sportsmodeller)
Frontgitterfremspring4": 17 mm (0.67")6,5": 19 mm (0.75") 7,7": 23 mm (0.91")
ModelserieXS Series
MærkeFusion
KapslingsklasseIP65
Installation and choosing accessories

Kontrollér impedans, RMS-effekt, monteringsdybde, udskæring og egnet forstærker. LED-funktioner kræver kompatibel styring.

Installation og kompatibilitet

Kontrollér udskæringsmål, monteringsdybde, impedans, RMS-effekt og kabeldimension. Ved udvendig montering skal placeringen passe til produktets vandklassifikation og kunne afvandes korrekt.

💡 Mit råd før bestilling

Jeg anbefaler, at model, strøm, stik og monteringsforhold bliver kontrolleret, før Fusion® XS Series marinehøjttalere, 120 watt klassisk marinehøjttaler (par) på 4" bestilles. Du er velkommen til at sende billeder og modelnumre, så hjælper jeg med vurderingen.

Full product description

Fusion® XS Series Marine Speakers, 120-Watt 4" Classic Marine Speaker (Pair) – Designed for life on board

With the Fusion® XS Series marine speakers, 120-watt 4" classic marine speaker (pair), you get marine speakers for a clearer and richer sound system on board. It is an obvious choice when the equipment needs to function as a well-thought-out part of the boat's overall installation, and you want to ensure both compatibility, mounting, and practical use on board.

⚡ Practical benefits

  • Speaker grilles (1 pair classic white/1 pair classic black)
  • 120-watt 4" classic marine speaker (pair)
  • Enjoy high-efficiency sound, improved environmental protection, and multi-color RGB LED lighting1 at a reasonable price with XS Series speakers from Fusion.
  • Targeted at marine installations where speakers are exposed to moisture, vibrations, and changing temperatures.
  • Can be combined with compatible Fusion stereos, amplifiers, and zone control.
  • Makes it possible to build a uniform sound solution in several areas of the boat.

⛵ Suitable for

  • Cockpit, salon, cabin, or flybridge
  • New sound installations and replacement of existing marine speakers
  • Boat owners who want help with impedance, power, placement, and cable dimensioning

📊 Specifications

Product/model Fusion® XS Series marine speakers, 120-watt 4" classic marine speaker (pair)
Manufacturer Fusion
Physical dimensions (diameter) 4" (classic): 135 mm (5.31")(Classic/sport) 6.5": 81 mm (6.97") (Classic/sport) 7.7": 196 mm (7.72")
Physical dimensions (depth) 4" (classic): 68 mm (2.68")(Classic) 6.5": 81 mm (3.19") (Sport) 7.7": 83 mm (3.27")(Classic) 7.7": 94 mm (3.7") (Sport) 7.7": 97 mm (3.82")
LED load current at 14.4 V DC (max.) 150 mA (select sport models only)
Frequency response (+/- 3 dB) 4": 100 Hz-18 kHz 6.5": 80 Hz-18 kHz 7.7": 70 Hz-18 kHz
Sizes 4"/6.5"/7.7"
Color Classic white/black or sport grey/white
Water and dust rating IP65
Speaker type Coaxial
Continuous power handling (RMS) 4": 30 W 6.5": 50 W 7.7": 60 W
Sensitivity (SPL at 1 W/1 m) 4": 87 dB 6.5": 91 dB 7.7": 92 dB
Nominal impedance 4 Ω
LED lighting Yes – RGB (select sport models only)
LED supply voltage 10.8-16 VDC (select sport models only)
Operating temperature 0° to 50° C (32° to 122° F)
Cone material 4": Polypropylene cone with rubber surround 6.5"/7.7": Polypropylene cone with fabric surround
Tweeter type Aluminum dome
Compass-safe distance 4": 255 cm (100.5") 6.5": 310 cm (122") 7.7": 400 cm (157.5")
Speaker connections Spade connectors
LED connection Terminated connections (select sport models only)
Mounting diameter, clearance 4": 99 mm (3.9") 6.5": 135 mm (5.31") 7.7": 162 mm (6.38")
Mounting depth, clearance 4": 54 mm (2.13") 6.5": 67 mm (2.64") 7.7": 77 mm (3.03")
Front grille protrusion 4": 17 mm (0.67") 6.5": 19 mm (0.75") 7.7": 23 mm (0.91")

📦 What's in the box

  • 12 Phillips stainless steel mounting screws (3.5 mm x 25.4 mm / 6 gauge x 1")
  • 12 Phillips stainless steel mounting screws (4.2 mm x 25.4 mm / 8 gauge x 1")

🔧 Installation and compatibility

Check the cutout dimensions, mounting depth, impedance, RMS power, and cable dimensions. For external installation, the placement must match the product's water rating and be able to drain correctly.

📄 Manuals and documentation

💡 My advice before ordering

I recommend verifying the model, power, connectors, and mounting conditions before ordering the Fusion® XS Series marine speakers, 120-watt 4" classic marine speaker (pair). You are welcome to send photos and model numbers, and I will help with the assessment.
