Garmin Panoptix LiveScope™ system
Gør plads til oplysningerne fra vandet under båden.
- Indgår i visning eller måling af de undervandsdata, modellen understøtter.
- Vægt: GLS 10 ekkolods-black box: 2,0 kgLVS32-TH transducer uden fairing block: 2,0 kgLVS32-TH transducer med fairing block: 2,3 kg
- Strømtilførsel: 10-32 V
- Strømforbrug: 21 W typisk, 58 W maks.
What is included
- To meter Garmin marinenetværkskabel, lille stik
- Netværksadapterkabel
- Hæk eller elmotor: Systemet omfatter monteringsbeslag til transduceren til både hæk og elmotor. Montering gennem skroget: Systemet omfatter monteringsudstyr til transduceren til montering gennem skroget.
Technical details
| Vægt | GLS 10 ekkolods-black box: 2,0 kgLVS32-TH transducer uden fairing block: 2,0 kgLVS32-TH transducer med fairing block: 2,3 kg |
|---|---|
| Maksimal dybde | Frem: 61 m |
| Strømtilførsel | 10-32 V |
| Strømforbrug | 21 W typisk, 58 W maks. |
| Produkt/model | Garmin Panoptix LiveScope™ system |
| Producent | Garmin |
| Fysisk størrelse (BxHxD) | GLS 10 ekkolods-black box: 24,5 x 14,9 x 6,5 cmLVS32-TH transducer uden fairing block: 24,4 x 4,6 x 13,7 cmLVS32-TH transducer med fairing block: 24,4 x 8,6 x 20,6 cm |
| Vandtæthedsklasse | IPX7 |
| Understøttede frekvenser | 530-1.100 kHz |
| Garmin Marine Network porte | 1 (lille stik) |
| Temperaturområde | GLS 10 ekkolodsboks I drift: -15 °C til 70 °CPanoptix LiveScope LVS12 transducer i drift: 0 °C til 40 °C |
| Sikring | 7,5 A |
| Sendestyrke | 500 W |
| Mærke | Garmin |
| Kapslingsklasse | IPX7 |
Installation and choosing accessories
Match transducer, frekvenser, stik, skroghældning og display. Et kompatibelt stik alene sikrer ikke alle funktioner.
Installation og kompatibilitet
Kontrollér transducertype, stik, frekvens, effekt, skrogmateriale, deadrise og monteringsform. Placeringen skal give transduceren så rent vandflow som muligt og passe til den kompatible Garmin-enhed.
💡 Mit råd før bestilling
Jeg anbefaler, at model, strøm, stik og monteringsforhold bliver kontrolleret, før Garmin Panoptix LiveScope™ system bestilles. Du er velkommen til at sende billeder og modelnumre, så hjælper jeg med vurderingen.
Full product description
Garmin Panoptix LiveScope™ system – developed for life on board
With the Garmin Panoptix LiveScope™ system, you get sonar or transducer equipment for viewing depth, bottom, fish, and structure beneath the boat. It is an obvious choice when the equipment needs to function as a well-integrated part of the boat’s overall installation, and you want to manage compatibility, mounting, and practical use on board.
⚡ Practical benefits
- LiveScope GLS 10 sonar black box
- Panoptix LVS32 transducer
- Through-hull mounting hardware
- Can provide a more detailed picture of bottom conditions and underwater objects depending on the chosen technology.
- Can be integrated into a compatible Garmin sonar system together with a chartplotter or black box.
- The correct choice depends on connector type, frequency, power, hull, and the desired mounting method.
⛵ Suitable for
- Fishing, depth sounding, and a better understanding of bottom conditions
- New Garmin sonar installations and upgrades
- Boat owners who want help with transducer, frequency, connector, and mounting
📊 Specifications
| Product/model | Garmin Panoptix LiveScope™ system |
|---|---|
| Manufacturer | Garmin |
| Physical size (WxHxD) | GLS 10 sonar black box: 24.5 x 14.9 x 6.5 cm LVS32-TH transducer without fairing block: 24.4 x 4.6 x 13.7 cm LVS32-TH transducer with fairing block: 24.4 x 8.6 x 20.6 cm |
| Weight | GLS 10 sonar black box: 2.0 kg LVS32-TH transducer without fairing block: 2.0 kg LVS32-TH transducer with fairing block: 2.3 kg |
| Water rating | IPX7 |
| Power input | 10-32 V |
| Power consumption | 21 W typical, 58 W max. |
| Supported frequencies | 530-1,100 kHz |
| Garmin Marine Network™ ports | 1 (small connector) |
| Temperature range | GLS 10 sonar box operating: -15 °C to 70 °C Panoptix LiveScope LVS12 transducer operating: 0 °C to 40 °C |
| Fuse | 7.5 A |
| Transmit power | 500 W |
| Maximum depth | Forward: 61 m |
📦 In the box
- Two-meter Garmin marine network cable, small connector
- Network adapter cable
- Transom or trolling motor: The system includes mounting brackets for the transducer for both transom and trolling motor. Through-hull: The system includes mounting hardware for the transducer for through-hull mounting.
🔧 Installation and compatibility
Verify transducer type, connector, frequency, power, hull material, deadrise, and mounting method. The location must provide the transducer with as clean a water flow as possible and suit the compatible Garmin device.
📄 Manuals and documentation
💡 My advice before ordering
I recommend that model, power, connector, and mounting conditions are checked before ordering the Garmin Panoptix LiveScope™ system. You are welcome to send photos and model numbers, and I will assist with the assessment.
