Garmin Fusion® Signature Series 3i Marine Speakers, 6.5" 230 watt Classic white coaxial marine speakers (set)
Giv musikken plads om bord, når kursen er sat og der er tid til at nyde turen.
- Til lydgengivelse som del af et kompatibelt lydsystem.
- LED belastningsstrøm ved 14,4 V DC (maks.): 300 mA (kun udvalgte sportsmodeller)
- Kontinuerlig effekthåndtering (RMS): 6,5": 75 W 7,7": 100 W8,8": 130 W
- Anbefalet forstærkereffekt (RMS): Oversigt 6,5": 25-160 med kanal 7,7": 25-220 med kanal8,8": 30-300 med kanal
What is included
- 12 Phillips monteringsskruer i rustfrit stål, 4,2 mm x 40 mm (8 gauge x 1,6")
Technical details
| Fysiske mål (diameter) | 6,5" (Classic): 200 mm (7,87") 6,5" (Sport): 176 mm (6,93")7,7" (Classic): 220 mm (8,66") 7,7" (Sport): 196 mm (7,72") 8,8" (Classic): 247 mm (9,75") 8,8" (Sport): 224 mm (8,82") |
|---|---|
| Fysiske mål (dybde) | 6,5" (Classic): 103 mm (4,06") 6,5" (Sport): 104,5 mm (4,11")7,7" (Classic): 109,5 mm (4,31") 7,7" (Sport): 111 mm (4,37") 8,8" (Classic): 131mm (5,16") 8,8" (Sport): 133mm (5,24") |
| Monteringsdiameter, frirum | 6,5": 136mm (5,35") 7,7": 156mm (6,14")8,8": 188mm (7,44") |
| Monteringsdybde, frirum | 6,5": 79 mm (3,11") 7,7": 86mm (3,39")8,8": 106mm (4,13") |
| LED belastningsstrøm ved 14,4 V DC (maks.) | 300 mA (kun udvalgte sportsmodeller) |
| Kontinuerlig effekthåndtering (RMS) | 6,5": 75 W 7,7": 100 W8,8": 130 W |
| Anbefalet forstærkereffekt (RMS) | Oversigt 6,5": 25-160 med kanal 7,7": 25-220 med kanal8,8": 30-300 med kanal |
| LED-forsyningsspænding | 10,8-16 VDC (kun udvalgte sportsmodeller) |
| Produkt/model | Garmin Fusion® Signature Series 3i Marinehøjttalere, 6,5" 230 watt Classic white koaksiale marinehøjttalere (sæt) |
| Producent | Fusion |
| Frekvensrespons (+/- 3 dB) | 6,5": 70 Hz-22 kHz 7,7": 60 Hz-22 kHz8,8": 50 Hz-20 kHz |
| Størrelser | 6,5"/7,7"/8,8" |
| Farve | Classic White, Sports White eller Sports Grey |
| Vand- og støvklassifikation | IP65 |
| Højttalertype | Koaksial |
| Følsomhed (SPL ved 1 W/1 m) | 6,5": 90 dB 7,7"/8,8": 91 dB |
| Nominel impedans | 4 Ω |
| LED-belysning | Ja - CRGBW (kun udvalgte sportsmodeller) |
| Driftstemperatur | 0° til 50° C (32° til 122° F) |
| Kegle materiale | CURV® Cone Technology med gummikant |
| Diskanttype | Silk-dome |
| Sikkerhedsafstand for kompas | 6,5": 310 cm (122") 7,7": 358 cm (141")8,8": 412 cm (162") |
| Højttalerforbindelser | Ikke-tilsluttet kabel med vandtæt tovejsstik, 150mm (5,9") |
| LED-forbindelse | Ikke-tilsluttet kabel med vandtæt seksvejsstik, 150 mm (5,9") (kun udvalgte sportsmodeller) |
| Frontgitterfremspring | 6,5": 29 mm (1,14") 7,7": 29 mm (1,14")8,8": 31 mm (1,34") |
| Modelserie | Signature |
| Mærke | Garmin |
| Kapslingsklasse | IP65 |
Installation and choosing accessories
Kontrollér impedans, RMS-effekt, monteringsdybde, udskæring og egnet forstærker. LED-funktioner kræver kompatibel styring.
Installation og kompatibilitet
Kontrollér udskæringsmål, monteringsdybde, impedans, RMS-effekt og kabeldimension. Ved udvendig montering skal placeringen passe til produktets vandklassifikation og kunne afvandes korrekt.
💡 Mit råd før bestilling
Jeg anbefaler, at model, strøm, stik og monteringsforhold bliver kontrolleret, før Garmin Fusion® Signature Series 3i Marinehøjttalere, 6,5" 230 watt Classic white koaksiale marinehøjttalere (sæt) bestilles. Du er velkommen til at sende billeder og modelnumre, så hjælper jeg med vurderingen.
Full product description
Garmin Fusion® Signature Series 3i Marine Speakers, 6.5" 230-watt Classic White Coaxial Marine Speakers (pair) – engineered for life on board
With the Garmin Fusion® Signature Series 3i Marine Speakers, 6.5" 230-watt Classic White Coaxial Marine Speakers (pair), you get marine speakers for a clearer and richer sound system on board. It is an obvious choice when the equipment needs to function as a well-integrated part of the boat's overall installation, and you want to ensure compatibility, proper mounting, and practical use on board.
⚡ Practical benefits
- One pair of speakers (based on your selection)
- 6.5" 230-watt Classic White coaxial marine speakers (pair)
- Defy the elements. Signature Series 3i coaxial speakers deliver crystal-clear audio and can withstand the conditions like never before.
- Targeted at marine installations where speakers are exposed to moisture, vibrations, and fluctuating temperatures.
- Can be combined with compatible Fusion stereos, amplifiers, and zone control.
- Makes it possible to create a uniform sound solution in several areas of the boat.
⛵ Suitable for
- Cockpit, saloon, cabin, or flybridge
- New audio installations and replacement of existing marine speakers
- Boat owners who want help with impedance, power, placement, and cable sizing
📊 Specifications
| Product/model | Garmin Fusion® Signature Series 3i Marine Speakers, 6.5" 230-watt Classic White Coaxial Marine Speakers (pair) |
|---|---|
| Manufacturer | Fusion |
| Physical dimensions (diameter) | 6.5" (Classic): 200 mm (7.87") 6.5" (Sport): 176 mm (6.93") 7.7" (Classic): 220 mm (8.66") 7.7" (Sport): 196 mm (7.72") 8.8" (Classic): 247 mm (9.75") 8.8" (Sport): 224 mm (8.82") |
| Physical dimensions (depth) | 6.5" (Classic): 103 mm (4.06") 6.5" (Sport): 104.5 mm (4.11") 7.7" (Classic): 109.5 mm (4.31") 7.7" (Sport): 111 mm (4.37") 8.8" (Classic): 131 mm (5.16") 8.8" (Sport): 133 mm (5.24") |
| LED load current at 14.4 V DC (max) | 300 mA (select sport models only) |
| Frequency response (+/- 3 dB) | 6.5": 70 Hz–22 kHz 7.7": 60 Hz–22 kHz 8.8": 50 Hz–20 kHz |
| Sizes | 6.5"/7.7"/8.8" |
| Color | Classic White, Sports White, or Sports Grey |
| Water and dust rating | IP65 |
| Speaker type | Coaxial |
| Continuous power handling (RMS) | 6.5": 75 W 7.7": 100 W 8.8": 130 W |
| Sensitivity (SPL at 1 W/1 m) | 6.5": 90 dB 7.7"/8.8": 91 dB |
| Nominal impedance | 4 Ω |
| Recommended amplifier power (RMS) | 6.5": 25–160 W per channel 7.7": 25–220 W per channel 8.8": 30–300 W per channel |
| LED lighting | Yes - CRGBW (select sport models only) |
| LED supply voltage | 10.8–16 VDC (select sport models only) |
| Operating temperature | 0° to 50° C (32° to 122° F) |
| Cone material | CURV® Cone Technology with rubber surround |
| Tweeter type | Silk-dome |
| Compass-safe distance | 6.5": 310 cm (122") 7.7": 358 cm (141") 8.8": 412 cm (162") |
| Speaker connections | Flying lead with waterproof 2-way connector, 150 mm (5.9") |
| LED connection | Flying lead with waterproof 6-way connector, 150 mm (5.9") (select sport models only) |
| Mounting diameter, clearance | 6.5": 136 mm (5.35") 7.7": 156 mm (6.14") 8.8": 188 mm (7.44") |
| Mounting depth, clearance | 6.5": 79 mm (3.11") 7.7": 86 mm (3.39") 8.8": 106 mm (4.13") |
| Grille protrusion | 6.5": 29 mm (1.14") 7.7": 29 mm (1.14") 8.8": 31 mm (1.34") |
📦 Package contents
- 12 stainless steel Phillips mounting screws, 4.2 mm x 40 mm (8 gauge x 1.6")
🔧 Installation and compatibility
Check cutout dimensions, mounting depth, impedance, RMS power, and cable size. For external mounting, the placement must suit the product's water rating and allow for proper drainage.
📄 Manuals and documentation
💡 My advice before ordering
I recommend that model, power, connectors, and mounting conditions are checked before ordering the Garmin Fusion® Signature Series 3i Marine Speakers, 6.5" 230-watt Classic White Coaxial Marine Speakers (pair). You are welcome to send photos and model numbers, and I will help with the assessment.
