Powerful high-current fuse for maximum protection of your 12V/24V/48V system.
The Victron MEGA-fuse 60A/80V (package of 5 pcs) is a robust bolt-on fuse designed to protect cables and electrical installations against overcurrent. It is typically used in energy systems where high demands are placed on safety and reliability.
MEGA fuses are suitable for high-current installations where a strong and stable connection is necessary.
⚡ Advantages
-
60A fuse for high-current installations
-
Up to 80V DC – ideal for 12V / 24V / 48V systems
-
Supplied in a pack of 5
-
Bolt-on connection for maximum contact and safety
-
Compact and robust design
-
Fast and reliable protection against overload
MEGA fuses are typically used in high-current energy systems where robust protection is crucial.
⛵ Suitable for
-
Battery banks
-
Inverters and chargers
-
Solar power systems and energy systems
-
Marine installations and off-grid solutions
📊 Specifications
| Specification | Data |
|---|---|
| Fuse type | MEGA (bolt-on) |
| Current | 60 A |
| Max. voltage | 80 V DC |
| Mounting | Bolt-on |
| Voltage drop | approx. 80 mV |
| Resistance | approx. 0.5 mΩ |
| Quantity | 5 pcs |
🔧 Installation
The fuse is typically mounted:
-
Close to the battery's positive terminal
-
In a MEGA fuse holder
-
Dimensioned according to cable thickness and load
📦 Package contents
-
5 × Victron MEGA-fuse 60A / 80V
💡 Tip from SejlStrøm:
60A MEGA fuses are ideal for small to medium-sized installations where you still need a robust solution for high current. Always choose a fuse based on cable dimension – not just consumption.
