PHOENIX BV integrated LED light – adjustable
Item no. SS-11220
Brug kompatibelt vekselstrømsudstyr med batteriet som energikilde.
- Omformer batteriets jævnstrøm til den angivne AC-udgang.
- Spænding: 10-30V DC
- Effekt: 3 W
- Materiale: Messing, forkromet
What is included
Leveres som vist. Eventuelt tilbehør afhænger af modellen.
Technical details
| Diameter | 67 mm |
|---|---|
| Diameter til montering | 54 mm |
| Dybde | 35 mm |
| Spænding | 10-30V DC |
| Effekt | 3 W |
| Lys | LED |
| Lysstyrke | 59 lm |
| Kan dæmpes | Ja, dæmpbar |
| Farvetemperatur | 3200K |
| Lysets farve | varm hvid |
| Vandtæt | IP65 |
| Materiale | Messing, forkromet |
| Mærke | Victron |
| Kapslingsklasse | IP65 |
Installation and choosing accessories
Sammenlign kontinuerlig effekt og startbelastning med forbruget. Batteri, sikring og kabler skal dimensioneres samlet.
Installation
Følg altid korrekt installationsvejledning og sørg for korrekt spænding og tilslutning.
Full product description
PHOENIX BV recessed LED light / adjustable is a quality solution for those who want reliable and efficient lighting on board.
The product is suitable for maritime environments where operational reliability and low power consumption are important. It is suitable for both new installations and upgrades.
⚡ Benefits
- Energy-efficient LED technology
- Suitable for marine environments
- Compact and functional design
- Easy installation
⛵ Suitable for
- Leisure boats
- Sailboats and motorboats
- Interior lighting
📊 Specifications
PHOENIX BV recessed LED light / adjustable from SVB24 is developed for use on board, where you want reliable and functional lighting.
At SejlStrøm, we select marine lighting with a focus on low power consumption, easy installation, and high operational reliability. This model is particularly suitable for recessed mounting in ceilings, side panels, or smaller spaces.
The PHOENIX BV recessed LED light is a real eye-catcher. It not only looks stylish, but its warm white light color also creates a pleasant atmosphere. This special lamp is also easy to install and has a robust housing made of chrome-plated brass.
Technical specifications
| Light | LED |
| Voltage | 10-30V DC |
| Wattage | 3 W |
| Brightness | 59 lm |
| Dimmable | Yes, dimmable |
| Color temperature | 3200K |
| Light color | warm white |
| Diameter | 67 mm |
| Mounting diameter | 54 mm |
| Depth | 35 mm |
| Waterproof | IP65 |
| Material | Brass, chrome-plated |
🔧 Installation
Always follow the correct installation instructions and ensure correct voltage and connection.
📦 Package contents
Supplied as shown. Any accessories depend on the model.
💡 Tip from SejlStrøm
Combine with suitable cables and installation accessories for a complete solution.
