Victron Precision Battery Monitor BMV-702 Black

Item no. VIC-10130

Victron Precision Battery Monitor BMV-702 Black

Få et bedre grundlag for at følge strømforbruget om bord.

  • Indgår i måling eller visning af batteriets strømforbrug og tilstand.
  • Måling: Spænding, strøm, kapacitet
  • Hulmål: ca. Ø52 mm
  • Vægt: ca. 0.3 kg
Price each
1.019,95 DKK

Includes VAT. Shipping calculated at checkout.

View delivery terms

Split your payment with ViaBill or Anyday

See amounts and terms with the provider. Choose your payment method at checkout.

Technical details
MålingSpænding, strøm, kapacitet
Hulmålca. Ø52 mm
Vægtca. 0.3 kg
Spændingsområde6.5 – 95 V DC
SpecifikationData
ProduktBMV-702 Black
Shunt500A / 50mV
Ekstra inputJa (batteri/temp/midpoint)
DisplayLCD
MonteringPanel (indbygning)
Dimensioner (display)ca. Ø63 mm (front)
AnvendelseBatteriovervågning
ModelserieBMV-702
MærkeVictron
FarveSort
Installation and choosing accessories

Match shunt, instrument, strømniveau og ledningsføring. Visning af ladetilstand kræver korrekt opsætning og kalibrering.

Full product description

Full control over your battery – with precise measurement and history.

The Victron BMV-702 Black is an advanced battery monitor that gives you a complete overview of your battery's condition. It measures voltage, current, power consumption, and state of charge in real time, so you always know how much power you have left.

The BMV-702 model also features an additional input, allowing you to monitor a second battery, temperature, or midpoint voltage – perfect for more advanced installations.

⚡ Benefits

  • Precise measurement of current, voltage, and capacity

  • Calculates battery state of charge (SOC)

  • Additional input for 2nd battery or temperature

  • History and data analysis

  • Programmable alarm relay

  • Low power consumption

  • Classic black design

The BMV series is known for its extreme precision and reliability.

⛵ Suitable for

  • Boats and marine installations

  • Camper vans and vans

  • Solar power systems and off-grid systems

  • All types of batteries (AGM, GEL, Lithium)

📊 Specifications

Specification Data
Product BMV-702 Black
Measurement Voltage, current, capacity
Shunt 500A / 50mV
Voltage range 6.5 – 95 V DC
Additional input Yes (battery/temp/midpoint)
Display LCD
Mounting Panel (flush mount)
Dimensions (display) approx. Ø63 mm (front)
Cutout approx. Ø52 mm
Weight approx. 0.3 kg
Application Battery monitoring

🔧 Installation

The unit is typically installed:

  • With shunt mounted on the battery's negative terminal

  • Display mounted in panel

  • Connected via included cables

📦 Package contents

  • 1 × Victron BMV-702 Black display

  • 1 × 500A shunt

  • Cables and mounting parts

💡 Tip from SejlStrøm:
If you only choose one thing for your battery – it should be a battery monitor. Voltage alone tells you nothing, but SOC does. The BMV-702 gives you a complete overview 👍
