Boat solar system 480Wh (120Wp) with MPPT

Item no. SS-10009

Boat solar system 480Wh (120Wp) with MPPT

120 W solcellepakke til bådens batteri. Vælg ét samlet panel eller to mindre paneler efter pladsen om bord; de konkrete mål vises for hver variant.

  • Samlet paneleffekt: 120 Wp i begge varianter
  • Vejledende produktion: Ca. 480 Wh/døgn i solrigt sommervejr
  • MPPT-regulator: 20 A, display, bly/AGM/GEL/LiFePO4
Your selected configuration

2 x 60W panels

Price each
2.399,00 DKK

Includes VAT. Shipping calculated at checkout.

Delivery within 1–3 days
View delivery terms

Split your payment with ViaBill or Anyday

See amounts and terms with the provider. Choose your payment method at checkout.

See what is included and what the installation requires

Does this product suit your needs?

Wp er panelernes mærkeeffekt under standardiserede testforhold. Wh pr. døgn er energi over en dag og afhænger af årstid, skygger, panelretning og forbrug. Et oplyst sommerudbytte er derfor ikke en garanti for daglig produktion eller drift af alle apparater samtidig.

Ønsker du 230 V, skal du også have en passende inverter. Beregn dit døgnforbrug i strøm- og solcelleberegneren. Ved rælingsmontering skal både rørdiameter og panelbredde passe til beslaget.

480 Wh pr. døgn dækker ikke nødvendigvis et køleskab sammen med bådens øvrige forbrug. Dimensionér efter køleskabets faktiske energiforbrug.

What is included

  • Valgte panelvariant: 1 × 120 Wp eller 2 × 60 Wp.
  • 20 A MPPT-regulator med display.
  • Panelkabler, MC4-stik og batterikabel med sikring.
  • Tilslutningsvejledning.
Technical details

Your selected configuration: 2 x 60W panels

Paneler2 × 60 Wp
Mål pr. panel676 × 492 × 25 mm
Vægt pr. panelCa. 4 kg
Samlet panelvægtCa. 8 kg
Vmp / Voc pr. panel19 V / 22,5 V
Samlet paneleffekt120 Wp i begge varianter
Vejledende produktionCa. 480 Wh/døgn i solrigt sommervejr
MPPT-regulator20 A, display, bly/AGM/GEL/LiFePO4
Regulatorens batterispænding12/24 V; panelopsætningen skal passe
Regulatormål175 × 145 × 50 mm
RegulatorbeskyttelseIP30 – tør indendørs placering
Batterikabel3 m, 2,5 mm², 30 A sikring
Installation and choosing accessories

Batteri og monteringsbeslag købes separat. Vælg regulatorens ladeprofil efter batteriet. Regulatoren monteres tørt og ventileret. Kabeltværsnit og sikring skal kontrolleres til den samlede længde, belastning og monteringsmåde; en medfølgende kabelpakke er ikke en universel dimensioneringsanvisning.

Ét 120 W-panel er til et 12 V-batterisystem. Til 24 V kræves to passende paneler i serie og kontrol af regulatorens spændingsgrænse. Vælg ikke 24 V alene ud fra regulatorens mærkning.

Full product description

120 W solar panel kit for boat batteries. Choose one single panel or two smaller panels depending on the space on board; specific dimensions are shown for each variant.

Technical specifications and dimensions

Total panel power 120 Wp in both variants
Estimated output Approx. 480 Wh/day in sunny summer weather
MPPT controller 20 A, display, lead-acid/AGM/GEL/LiFePO4
Controller battery voltage 12/24 V; panel setup must match
Controller dimensions 175 × 145 × 50 mm
Controller protection IP30 – dry indoor installation
Battery cable 3 m, 2.5 mm², 30 A fuse

2 × 60 W panels

Panels 2 × 60 Wp
Dimensions per panel 676 × 492 × 25 mm
Weight per panel Approx. 4 kg
Total panel weight Approx. 8 kg
Vmp / Voc per panel 19 V / 22.5 V

1 × 120 W panel

Panels 1 × 120 Wp
Panel dimensions 915 × 676 × 25 mm
Panel weight Approx. 7.2 kg
Vmp / Voc 17.6 V / 20.9 V

What's included

  • Selected panel variant: 1 × 120 Wp or 2 × 60 Wp.
  • 20 A MPPT controller with display.
  • Panel cables, MC4 connectors, and battery cable with fuse.
  • Connection instructions.

Compatibility and installation

Battery and mounting brackets are sold separately. Select the controller's charging profile according to the battery. The controller must be installed in a dry and ventilated area. Cable cross-section and fuse rating must be verified based on total length, load, and installation method; the included cable kit is not a universal sizing guide.

One 120 W panel is for a 12 V battery system. For 24 V, two suitable panels in series are required, and the controller's voltage limit must be checked. Do not choose 24 V based solely on the controller's label.

Good to know before purchasing

Wp is the panels' rated power under standardized test conditions. Wh per day is energy over a day and depends on the season, shadows, panel orientation, and consumption. The stated summer output is therefore not a guarantee of daily production or the operation of all appliances simultaneously.

If you need 230 V, you must also have a suitable inverter. Calculate your daily consumption in the power and solar calculator. For rail mounting, both the pipe diameter and panel width must fit the bracket.

480 Wh per day does not necessarily cover a refrigerator along with the boat's other consumption. Size according to the actual energy consumption of the refrigerator.
