Victron Precision Battery Monitor BMV-702
Item no. VIC-10129
Få et bedre grundlag for at følge strømforbruget om bord.
- Indgår i måling eller visning af batteriets strømforbrug og tilstand.
- Måling: Spænding, strøm, SOC
- Hulmål: 52 mm
- Vægt: ca. 0.3 kg
Technical details
| Måling | Spænding, strøm, SOC |
|---|---|
| Front diameter | 63 mm |
| Hulmål | 52 mm |
| Dybde | 31 mm |
| Vægt | ca. 0.3 kg |
| Spændingsområde | 6.5 – 95 V DC |
| Batterikapacitet | 1 – 9999 Ah |
| Specifikation | Data |
| Produkt | BMV-702 |
| Shunt | 500A / 50mV |
| Kommunikation | VE.Direct |
| Ekstra input | Ja (batteri/temp/midpoint) |
| Display | LCD |
| Montering | Indbygning (flush) |
| Front bezel | 69 × 69 mm |
| Shunt terminal | M10 |
| IP klasse | IP55 |
| Anvendelse | Batteriovervågning |
| Modelserie | BMV-702 |
| Mærke | Victron |
| Kapslingsklasse | IP55 |
Installation and choosing accessories
Match shunt, instrument, strømniveau og ledningsføring. Visning af ladetilstand kræver korrekt opsætning og kalibrering.
Full product description
Precise battery monitoring with advanced features.
The Victron BMV-702 is a high-precision battery monitor that measures voltage and current, and calculates the battery's state of charge (SOC) and consumption in real time. It gives you a complete overview of your energy system and helps you avoid unexpected power failures.
What makes the BMV-702 unique is the additional input, which can be used to measure a second battery, temperature, or midpoint – perfect for more advanced installations.
⚡ Benefits
-
Precise measurement of voltage, current, and capacity
-
Calculates battery state of charge (SOC)
-
Displays “time remaining” and consumption
-
Additional input for battery / temperature / midpoint
-
History and data analysis
-
Programmable alarm relay
-
VE.Direct for GX integration
The BMV series is known for its extreme precision and reliability.
⛵ Suitable for
-
Boat and marine installations
-
Motorhomes and vans
-
Solar power systems and off-grid systems
-
AGM, GEL, and lithium batteries
📊 Specifications
| Specification | Data |
|---|---|
| Product | BMV-702 |
| Measurement | Voltage, current, SOC |
| Shunt | 500A / 50mV |
| Voltage range | 6.5 – 95 V DC |
| Battery capacity | 1 – 9999 Ah |
| Communication | VE.Direct |
| Additional input | Yes (battery/temp/midpoint) |
| Display | LCD |
| Mounting | Flush mount |
| Front diameter | 63 mm |
| Front bezel | 69 × 69 mm |
| Hole diameter | 52 mm |
| Depth | 31 mm |
| Shunt terminal | M10 |
| Weight | approx. 0.3 kg |
| IP rating | IP55 |
| Application | Battery monitoring |
🔧 Installation
The unit is typically installed by:
-
Mounting the shunt on the battery negative
-
Mounting the display in a panel
-
Connecting via the included cables
-
Optionally connecting to a GX system
📦 In the box
-
1 × Victron BMV-702 display
-
1 × 500A shunt
-
10 m cable + fuse cable
-
Mounting parts
💡 Tip from SejlStrøm:
The BMV-702 is the "sweet spot" if you want a bit more than the basics. You get an extra input (e.g., temperature), which actually provides quite a lot of value in practice 👍
